Wilkens LiteWalker® Trailer
Discover the Ultimate in Customization with the LiteWalker® Trailer!
Designed specifically for feed, fertilizer, and seed, the LiteWalker® trailer is built to your exact specifications. Whether you need a specific height, length, or width, we have the perfect trailer for you.
Call us today to customize your Wilkens LiteWalker® trailer and experience the ultimate in efficiency and performance!
Why Choose the LiteWalker® Trailer?
- Light Weight: Increasing fuel-efficiency.
- Fast Unloading: THE fastest unloading system available, saving you valuable time.
- High Cube Design: Maximizes your load capacity for greater efficiency.
- Craftsman Constructed: Stainless steel Hydraulic lines, all fastener constructed, stainless steel fastened bottom rail.
- Innovative Patented Design
Specifications and Options:
- Length: Available up to 57′.
- Side & Overall Height: Choose from 9′ up to 14′ 6″.
- Open-Top: Options include Flat Top Hinge or Cathedral up to 16″ arch.
- Width: Available in 96″ or 102″ wide.
- Box: Straight design for optimal load distribution.
- Wheel Wells: Optimizing overall volume.
- 5th Wheel Height: Customizable, with 49″ as standard.
- Kingpin Setting: Adjustable from 27″ to 60″.
- Upper Coupler: Domex with Grease Saver Rods.
- Panels: .063″ thickness.
- Post Centers: Options of 14.75″ or 21.75″.
- Crossmembers: Available in steel or aluminum.
- Crossmember Centers: 12″ spacing for added strength.
- Landing Gear: Jost 2-Speed, with optional bolt-on aluminum gear and frame.
- Subframe: Slider rail or fixed axle with I-beam or Z frame.
- Undercarriage Finish: Black undercoat for protection.
- Suspension: AR Slider, fixed, or spread with up to 4 axles.
- Axles: TP with centers ranging from 49″ to 128″.
- Manual Air Dump: Mounted on slider or landing gear.
- Hub & Drum: Steel hub with cast drum, optional centrifuse or disc brakes.
- Brakes: 16.5″ x 7″ Q-Series, with optional disc brakes.
- Rim: Hum-Pilot Unimount.
- Wheels: Steel with white finish, or Alcoa polished Dura-Bright.
- Tires: Standard Goodyear, with other brands available.
- ABS Brakes: 1S/2M for two wheels.
- Mud-Flaps: Anti-spray and anti-sail.
- Drive Unit: Keith.
- Flooring: Ag rated to severe duty options available.
- Subfloor: Aluminum.
- Hydraulic Hoses: (2) 3/4″ x 10′.
- Hydraulic Fittings: Choice of options.
- Filter: High pressure.
- Slope Board: Standard slope.
- Side Seal: Standard aluminum or UHMW.
- Nose: 4 1/4″ inverted finish.
- Catwalk: Optional.
- Ladders: Standard ladder or cast steps.
- Rear Unit: Stainless steel or aluminum.
- Bumper: Aluminum DOT safety bumper or stainless steel.
- Doors: Double barn door or single swing top hinge.
- Door Latch: Steel rods or manual bottom latch, with optional stainless steel.
- Tarps: 18 oz. choice of color, with optional 22 oz. vinyl/mesh reinforced.
- Tarp System: Shur-Lok, with optional electric tarp or standard rollover.
- Tarp Crank: Front or rear, with optional remote for electric tarp.
- Tarp Bows: Minimum of two, arched.
- Tarp Bib: Standard on rear unit.
- Air Scale: Built-in, with optional 3rd glad hand scales.
- Electrical: (1) Grote main 7-way or (2) main, with different styles and pins available.
- Lighting: Grote high count LED, with choice of options.
Additional Options:
- Rear header turn signals
- Hubodometer
- Corded & cordless remotes
- Vents
- Broom & shovel holders
- Tire carriers
- Tarp supports
- Cargo lights
- Back-up lights
- Self-contained hydraulic units
- Product guards
- Illuminated flap hangers
- Toolboxes
- and MANY MORE
Call us today to customize your Wilkens Lite-Walker® trailer and experience the ultimate in efficiency and performance!
